HSS-400 Vineyard Herbicide Sprayer

Standard Features

Tank: 400 gal. stainless steel tank with 2" fill, mechanical agitation (jet agitation used with centrifugal pumps)

Chassis: Heavy-duty rectangular tube construction with axle using 3500 lb. Ag hub and spindles

Controls: Tractor-mounted control manifold with pressure regulator, pressure gauge, and independent spray boom shutoff valves

Pump: Choice of P.T.O. driven Comet P48 diaphragm pump, Ace hydraulic centrifugal pump, or engine-driven centrifugal pump

Spray Booms: Aluminum spray hoods adjustable for 10’–12’ rows, adjustable height, and breakaway hinges

Spray Wand: Single rear-mounted 36" hand spray wand with 30’ hose and quick-disconnect connections for easy removal

Filters: One suction filter and four discharge filters mounted for each boom for easy access and cleaning

Wheels: Heavy-duty 15 x 10 6-on-6 wheel, 12-ply 12.5L–15 rib implement flotation tires

Drive Shafts: Size 4 w/ CV

Options

Single hydraulic chemical shut-off valve.
Single electric shut off valve with control box
Single tee-jet electric solenoid shut off valve wwith toggle switch control box.
Inline flow meter
PTO-to-hydraulic driven diaphragm pump conversion kit. Requires 8 GPM hydraulic flow from tractor.
Dual-spot spray wands

The HSSV 400 Vineyard Herbicide Sprayer offers growers a reliable, mid-capacity solution for vineyard herbicide application. With a 400-gallon stainless steel tank, adjustable aluminum spray booms for 10’–12’ rows, and heavy-duty chassis construction, this sprayer is designed for both durability and performance. Equipped with multiple pump options, stainless steel plumbing, and flotation tires, it delivers consistent coverage and ease of maintenance. Compact yet rugged, the HSSV 400 is built to keep vineyard operations efficient season after season.

Specifications

Single hydraulic shut off valve
Single electric shut off valve with control box
Three electric shut off valve with control box (Allows for independent spray boom control)
All electric tractor cab mounted controls (Allows operator control of pressure regulator, spray booms from tractor cab)
Sprayer mounted boom flow meters
Hydraulic driven Comet P48 diaphragm pump
Dual mounted hand spray wand
